With a focus on product quality, Positioning pursues perfection in every detail.Positioning has the ability to meet different needs. power diode is available in multiple types and specifications. The quality is reliable and the price is reasonable.
Company Advantages
1. Positioning types of diode is under constant control in respect of safety and compliance with applicable international refrigeration system standards, as evidenced by the CE certificate of conformity issued.
2. The product features flammability resistance. It has passed the fire resistance testing, which can ensure that it does not ignite and pose risk to lives and property.
3. The product is very breathable, allowing air to move around freely and releasing moisture very fast, which keeps the bacteria and mildew away.




Conducting



Parameter



Symbol



Min



Max



Typ



Unit



Conditions



Average value of forward current



IF(AV)




6300




A

50Hz sinewave,180conduction, Tc = 126 °C



RMS value of forward current



IF(RMS)




9890




A


Peak one cycle surge

(non repetitive) current



IFSM




70




kA

50Hz sinewave,180conduction, Tj = Tjmax, V= 0



I square t



It




24500




kA2s



Tj = Tjmax



Peak forward voltage



VFM




1.14




V



Forward current 10 kA, Tjmax



Threshold voltage



VF(TO)




0.7




V



Tj = Tjmax



Forward slope resistance



rF




0.046




m



Tj = Tjmax

good types of diode specifications for switch reviews-1good types of diode specifications for switch reviews-2good types of diode specifications for switch reviews-3good types of diode specifications for switch reviews-4

good types of diode specifications for switch reviews-5good types of diode specifications for switch reviews-6



Company Features
1. Yangzhou Positioning Tech. Co., Ltd develops rapidly in the industry. We have won an honorable reputation for the customized service on signal diode .
2. We have a strong technology team. They are all highly educated senior experts in this field. With their abundant knowledge and industry know-how, they can escort the quality of products.
3. Strict management, tight production, good quality is Yangzhou Positioning Tech. Co., Ltd's strategic guidelines. Check now! high power diode has long been the pursuit of Yangzhou Positioning Tech. Co., Ltd. Check now!
Each Positioning signal diode consists of certified raw materials as standard. Most of the products have passed the certification of C E, R o H S, T U V. U L
high power diode is developed using latest technology support. Xindali is a professional manufacturer for push button switch & emergency push button since 1997
This product is reliable, efficient, attractive, has flawless finishing and so many qualities. Products are mainly sold in the European market and have their own brand agents in Italy, Germany, Poland and so on
High quality raw materials: When Positioning signal diode is created, they are carefully selected from reliable industrial suppliers to ensure their longevity. Also, many trials are carried out to select the right material before they enter the factory. Xindali Was built since 1997, focus on the button switch industry, is located in the famous low voltage appliance market Liushi in Wenzhou City
Positioning signal diode is designed to provide customers with choice and flexibility. Xindali Was built since 1997, focus on the button switch industry, is located in the famous low voltage appliance market Liushi in Wenzhou City
Many customers are satisfied with the high quality of this product. Xindali has more than 70 patents now, and there are some other series are under application of International PCT
